Assembly: Brownbuilt sheeting shall be laid in strict
accordance with manufacturer's specification by a Brownbuilt
approved erector.
A five year guarantee of site-workmanship and water-tightness shall be issued after approval by Brownbuilt Metal Sections
|
|
Profile
|
 |
|
|
The Concealed Fixing Method
|
|
|
| Available In: Galvanised,
Stainless Steel, Copper, Classicoat Colour Coated, Translucent Sheeting
(GRP) |
|
|
0.6mm
CQ Steel |
0.8mm
CQ Steel |
0.8mm
Aluminium |
0.9mm
Aluminium |
0.6mm
Stainless Steel |
| Roofs |
|
|
|
|
|
| Single Span |
1.500m |
2.400m |
1.200m |
1.500m |
1.500m |
| Internal Span |
1.800m |
2.700m |
1.500m |
1.800m |
1.800m |
| End Span |
1.500m |
2.400m |
1.200m |
1.500m |
1.500m |
| Cantilever |
0.200m |
0.300m |
0.100m |
0.100m |
0.200m |
| Cantilever, gutter attached |
0.450m |
0.600m |
0.100m |
0.100m |
0.450m |
| Single Span with Tile
Finish |
1.200m |
2.150m |
- |
0.800m |
1.200m |
| Internal Span with Tile
Finish |
1.500m |
2.400m |
- |
1.000m |
1.500m |
| Cantilever with Tile Finish |
0.220m |
0.300m |
- |
- |
0.220m |
|
|
|
|
|
|
| Walls |
|
|
|
|
|
| Internal Span |
2.700m |
3.000m |
1.500m |
1.800m |
2.700m |
| Cantilever |
400 |
600 |
|
|
|
| Normal mass
kg/mē |
8.16 |
10.26 |
3.61 |
4.05 |
8.16 |
|
|
|
Drainage Table
|
| Maximum roof run (in metres) for
roof slopes and rainfall intensities shown
|
| Rainfall Intensity
mm/h |
| 1
in 50 (1°) |
1
in 30 (2°) |
1
in 20 (3°) |
1
in 12 (5°) |
1
in 7.5 (7.5°) |
1
in 6 (10°) |
|
|
|
| 100 |
|
|
|
|
|
| 85 |
100 |
|
|
|
|
| 63 |
80 |
94 |
|
|
|
| 51 |
64 |
75 |
90 |
100 |
|
|
|
|
|
|
Underslung - Brownbuilt
|
|
|
