Klip-Lok 700
|
 |
Assembly: Klip-Lok 700 sheeting shall be laid in strict
accordance with manufacturer's specification by Brownbuilt
approved erector.
A five year guarantee of site-workmanship and water-tightness
shall be issued after approval by Brownbuilt Metal Sections
|
|
Profile
|
 |
|
|
The Concealed Fixing Concept
|
 |
| Available In: Galvanised,
Zincalume, Classicoat Colour Coated, Translucent Sheeting
(Polycarbonate & GRP) |
|
|
Light
Industrial (0.5mm) |
Heavy
Industrial (0.6mm) |
| Roofs |
|
|
| Single Span |
1.400m |
1.800m |
| End Span |
1.700m |
2.100m |
| Internal Span |
2.000m |
2.500m |
| Cantilever |
0.180m |
0.260m |
| Cantilever, gutter attached |
0.400m |
0.600m |
|
|
|
| Walls |
|
|
| Single Span |
2.100m |
2.300m |
| End Span |
2.500m |
2.600m |
| Internal Span |
2.500m |
2.800m |
| Cantilever |
0.300m |
0.500m |
| Normal mass
kg/mē |
5.50 |
6.60 |
|
|
|
Drainage Table
|
| Maximum roof run (in metres)
for roof slopes and rainfall intensities shown |
|
| Rainfall Intensity
mm/h |
| 1
in 50 (1°) |
1
in 30 (2°) |
1
in 20 (3°) |
1
in 12 (5°) |
1
in 7.5 (7.5°) |
1
in 6 (10°) |
|
|
|
| 64 |
80 |
94 |
|
|
|
| 53 |
66 |
78 |
95 |
|
|
| 40 |
50 |
58 |
70 |
83 |
91 |
| 32 |
40 |
46 |
56 |
66 |
73 |
|
|
|
|
