Armorflex
Armorflex erosion control system provides an alternative for a wide variety of erosion control and drainage projects.  Armorflex system is flexible, conforming to ground contours, settling without a fracture, and requires limited ground preparation.


Concrete Quality  Dimensions
(length/Breadth/Height)		 Normal Plan Size of Block No. Blocks p/m2 Weight of Block Unit Weight  Open Area Vol. material to fill joints & voids Mat sizes Cable Vertical Bending Radius
25mpa
    L=340mm B=294mm H=115mm
309 x 294 11 16.4kg ave 180kg/m2 (mat6.2m x 2.4m + lifting beam= +3.2t) 18% 0.022m3/m2 Standard 6.2m x 2.4m (20blocks x 6 blocks) Factory assembled - Galvanised steel wire rope or synthetic rope. In situ assembled - Galvanised fencing wire or synthetic rope 0.5m to 1.0m
ARMORFLEX 140 Armorflex is a registered product of Nicolon B.V.Holland and is manufactured and supplied under licence in South Africa by Concor Technicrete.
25mpa
    L=340mm B=400mm H=95mm
309 x 400 8 17.5kg ave 140kg/m2 (mat6.2m x 2.4m + lifting beam= +2.9t) 18% 0.022m3/m2 Standard 6.2m x 2.4m (20blocks x 6 blocks) Factory assembled- Galvanised steel wire rope or synthetic rope. In situ assembled - Galvanised fencing wire or synthetic rope 0.5m to 1.0m
ARMORFLEX 215SP CONCOR RESERVES THE RIGHT TO AMEND THE ABOVE SPECIFICATIONS WITHOUT NOTICE
25mpa
    L=442mm B=294mm H=115mm
412 x 294 8.3 25.9kg ave 215kg/m2 - - Standard 6.2m x 2.4m Factory assembled - Galvanised steel wire rope or synthetic rope. In situ assembled - Galvanised fencing wire or synthetic rope 0.5m to
